Your 2004 Cadillac SRX uses 6x115 wheels in 17"–18" OE diameters. Use the fitment table and filters below to narrow the right setup fast.
The fitment table shows the available bolt-pattern, hub-bore, offset, and size records for the 2004 Cadillac SRX. A year, make, and model can have multiple trims and brake packages, so confirm the applicable row and use each product's fitment status before ordering.
Browse the available alloy and steel wheel results for the 2004 Cadillac SRX and review each product's fitment status. Shipping eligibility and charges depend on the product, destination, and service and are confirmed during checkout. For fitment help, call 1-866-461-2787.
Do not assume a different diameter is compatible from bolt pattern or rolling diameter alone. Confirm width, offset, hub bore, load rating, brake clearance, tire requirements, and the applicable trim before changing from the factory specification.
Compare wheels for the 2004 Cadillac SRX. Confirm trim, width, offset, hub bore, load rating and brake clearance; product fitment is shown per item.
Looking for Cadillac SRX wheels? Compare the alloy and steel wheel results associated with the 2004 Cadillac SRX. Check the applicable trim and each product's fitment result; year, make and model alone do not confirm width, offset, hub bore, load rating or brake clearance.
Use diameter and the documented vehicle specifications as starting constraints, not a compatibility guarantee. Shipping eligibility and charges are confirmed for the product, destination and service at checkout. Need help? Call 1-866-461-2787.
Shop by wheel size
Pick a diameter, width and offset to check them against your vehicle. We check bolt-up, hub fit and stance.
Popular choices for your 2004 Cadillac SRX
Staggered fitment — the front and rear sizes are different. Buy 2 of each, not 4 of one.
| Position | OEM Size | Bolt Pattern | OEM Offset | Hub Bore | Lug Seat | Tire Size | Load Index | Speed Rating | Thread | Torque | TPMS |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Front | 17x7.5 | 6x115 | 37mm | 70.3mm | 60° Conical | 235/65R17 | 103 | H | M12x1.5 | 100 | Equipped |
| Rear | 17x7.5 | 6x115 | 37mm | 70.3mm | 60° Conical | 255/60R17 | 105 | H | M12x1.5 | 100 | Equipped |
| Front | 18x8 | 6x115 | 40mm | 70.3mm | 60° Conical | 235/60R18 | 102 | V | M12x1.5 | 100 | Equipped |
| Rear | 18x8 | 6x115 | 40mm | 70.3mm | 60° Conical | 255/55R18 | 104 | V | M12x1.5 | 100 | Equipped |
RTX Steel
Part #: X45512
Fits 2004 Cadillac SRX
CA$122.00
per wheel
4 wheels · CA$488.00
12+ in stock
Ships Wednesday (est.) 🚚Fast HD
Part #: F224A-1780-64FN+40C726
Fits 2004 Cadillac SRX
CA$220.49
per wheel
4 wheels · CA$881.96
Only 7 left
Ships Wednesday (est.) 🚚Fast HD
Part #: F224A-1880-64FN+40C726
Fits 2004 Cadillac SRX
CA$265.99
per wheel
4 wheels · CA$1,063.96
12+ in stock
Ships Wednesday (est.) 🚚Fast HD
Part #: F224A-1780-64FN+20C726
Aggressive fit — verify wheel well clearance before installing.
CA$220.49
per wheel
4 wheels · CA$881.96
12+ in stock
Ships Wednesday (est.) 🚚Fast HD
Part #: F224A-1880-64FN+20C726
Aggressive fit — verify wheel well clearance before installing.
CA$265.99
per wheel
3 wheels · CA$797.97
Only 3 left
Ships Wednesday (est.) 🚚DUB
Part #: S1102085D1+42
Aggressive fit — verify wheel well clearance before installing.
CA$453.00
Sale price in cart
per wheel
4 wheels · CA$1,812.00
12+ in stock
Ships week of Oct 19 (est.) 📦
